Trail Tamer

Equipped with a suspension fork, the Rove provides extra comfort and control, ready to tackle gravel and trails the moment you venture off the beaten path.

Confident Cruiser

Thanks to responsive, reliable disc brakes, you'll always have speed management at your fingertips, rain or shine.

Practical Partner

With integrated mounts for a rear cargo rack and a low standover height for easy mounting and dismounting, the Rove turns bike errands into a hassle-free experience.

Specifications

  • Sizes
    XS, S, M, L
  • Colors
    Rosy Brown
  • Frame
    ALUXX-grade aluminum, disc
  • Fork
    SR Suntour 700c, 63mm, QR
  • Shock
    Giant Connect XC, 31.8mm, 9-degree/6-degree rise, XS: 640mm, S: 640mm, M: 680mm, L: 680mm
  • Handlebar
    Giant Connect XC, 31.8mm, 9-degree/6-degree rise, XS: 640mm, S: 640mm, M: 680mm, L: 680mm
  • Stem
    Giant Sport, XS: 70mm, S: 80mm, M: 80mm, L: 90mm
  • Seatpost
    Giant D-Fuse, alloy, XS: 300mm, S: 300mm, M: 300mm, L: 350mm
  • Saddle
    Liv Ergo Contact
  • Pedals
    platform
  • Shifters
    Shimano Altus, 2x8
  • Front Derailleur
    Shimano Tourney
  • Rear Derailleur
    Shimano Altus
  • Brakes
    Tektro TKD143, hydraulic disc, [F]160mm, [R]160mm
  • Brake Levers
    Tektro TKD149
  • Cassette
    CS-HG31, 11x34
  • Chain
    KMC Z8.3
  • Crankset
    forged alloy, 30/46 with chain guard, XS: 165mm, S: 170mm, M: 170mm, L: 170mm
  • Bottom Bracket
    threaded
  • Rims
    Giant SX Disc
  • Hubs
    alloy, 28h
  • Spokes
    stainless steel, 14g
  • Tires
    Giant CrossCut, 700x42c, puncture protect
  • Extras
    55c max tire size without fender, 45c max tire size with fender, reflective stickers, kickstand, fender and rack frame mounts
  • Max Tire Clearance
    55mm
*All specifications and prices listed are subject to change without notice.

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.

    XS S M L
A Seat Tube Length (MM) 380 420 460 500
B Seat Tube Angle 74.0° 73.5° 73.0° 73.0°
C Top Tube Length (MM) 550 570 590 610
D Head Tube Length (MM) 110 120 135 150
E Head Tube Angle 70.5° 70.5° 70.5° 70.5°
F Fork Rake (MM) 42 42 42 42
G Trail (MM) 85.1 85.1 85.1 85.1
H Wheelbase (MM) 1059 1074 1089 1109
I Chain Stay Length (MM) 450 450 450 450
J Bottom Bracket Drop (MM) 62 62 62 62
K Stack (MM) 601 611 625 639
L Reach (MM) 378 389 399 415
M Stand Over Height (MM) 589 606 619 629
N Handlebar Width (MM) 640 640 680 680
O Stem Length (MM) 70 80 80 90
P Crank Length (MM) 165 170 170 175
